V-T3020ATP-BR430H Automatic pocket attach machine for jeans
2026-03-19
//www.vmasewing.com/v-t3020atp-br430h-automatic-pocket-attach-machine-for-jeans-with-reinforcement-function.html?is_preview=9bfc23efc805e530b81f2c5b016cf514
Description
1.Special suggestions and instructions: The DDE-8000A and Brother 7300 head just only suitable for sewing medium and thin materials, while the knotting machine head and pattern machine head can be compatible with sewing thick and thin materials, After installing the presser foot, perfect sewing effect can be achieved.
2.Computer program controlling，Servo + pneumatic drive, it is easy for operation.
Appllication: Jeans, knitwear, shirts, work clothes, leisure wear, military uniforms and back pockets, and it can also sew the bag cover at the same time，can be customized.
Specification: 1. Min pocket area: 45mm*45mm 2. Max pocket area: 280mm*280mm 3. Max speed: 3000~3600RPM 4. Stitch length: 0.1-12.7mm
5. Pattern quantity in memory: 9999+USB memory 6. Production Capacity(per hour): 240~350pcs
7. Power: 220V 50/60Hz, 1.25KW 8. Air Pressure: 5 Bar 9. Air Consumption: 230L/min 10. N.W/ G/W: 440KG/ 540~550KG
11. Machine Size(L*W*H cm): L170*W145*H165cm 12. Package Size(L*W*H cm): L190*W165*H185cm
Video Display
